Dip Switches

Get a Price/Quote

Dip Switches Specification

Input
Manual toggle input

Output
Binary signal output

Components
Plastic body, gold or silver plated contacts

Power Source
Manual

Power Supply
Not required (mechanical switch)

Interface
PCB Pin

Usage
Electronic devices, communication equipment

IP Rating
IP20

Response Time
Instantaneous (mechanical)

Features
RoHS compliant, easy DIP mounting, gold plated contacts

Operating Temperature
-40°C to +85°C

Product Type
DIP (Dual In-line Package) Switch

Application
PC boards, configuration settings, address selection

Rated Voltage
24V DC

Supply Voltage
Up to 24V DC

Size
Standard DIP

Dimension (L*W*H)
25 x 9 x 3 mm (LxWxH)

Function
ON/OFF circuit selection, manual configuration of digital signals

Color
Red and White

Weight
2 grams (approx.)

Thickness
3.0 mm (approx.)

Current Rating
25 mA max

Life Span
2000 cycles per switch (minimum)

Body Material
Flame-retardant plastic (UL94V-0 rating)

Contact Material
Gold or silver over nickel

Number of Positions
8-way (8 positions)

Mounting Type
Through Hole

Contact Resistance
100 m max

Insulation Resistance
100M min at 500V DC

Actuator Type
Slide

Dielectric Strength
500V AC for 1 minute

Dip Switches About

Cosmic Devices supplies an array of Dip Switches Relays to our respected clients well-known for their effectiveness and durability. They are available in different sizes and as per the requirements and specifications of our customers.

Features:

1. Durable

2. Easy installation

3. Heat resistant

Reliable ON/OFF Switch for Accurate Signal Selection

This 8-way dip switch excels at manual configuration of digital signals, making it indispensable for applications requiring precise ON/OFF circuit selection. Its slide actuator ensures quick and consistent operation, ideal for tasks like address configuration on PC boards. With instantaneous response time and robust construction, this switch helps simplify complex set-ups and supports efficient workflow in electronics and communication systems.

Durable and SafeBuilt for Demanding Environments

Constructed from flame-retardant plastic rated at UL94V-0, this switch withstands temperatures from -40C to +85C, ensuring safe and stable performance. Gold or silver plated contacts minimize resistance and maximize signal integrity. The device meets RoHS standards, supports up to 24V DC, and operates without a power supply, making it a cost-effective and environmentally conscious choice for professionals and hobbyists alike.

FAQs of Dip Switches:

Q: How is this 8-way dip switch used for circuit configuration on PC boards?

A: The dip switch is manually toggled using its slide actuators to set binary signals, enabling specific circuit selections or address settings on PC boards. Each of the eight positions can independently be switched ON or OFF for versatile customization.

Q: What are the main benefits of gold or silver plated contacts in this dip switch?

A: Gold or silver plating over nickel ensures improved conductivity, reduces contact resistance, and provides enhanced corrosion resistance, resulting in more consistent performance and longer switch life.

Q: Where is the most suitable placement for this dip switch during installation?

A: The switch is designed for through-hole mounting directly on printed circuit boards (PCBs), making it ideal for electronic assemblies such as configuration modules and communication equipment.

Q: What is the process for manually configuring settings using this dip switch?

A: Configuration is accomplished by sliding individual actuators to ON or OFF positions. Each switch position represents a binary value, so users can establish multiple configuration patterns depending on their application needs.

Q: When should this switch be considered over other input devices?

A: This dip switch is most appropriate when simple, reliable manual input is required for occasional configuration, such as during setup or initial calibration of electronic devices, where software-based switching may be impractical.

Q: What assurance is there regarding safety and durability of the switch body material?

A: The body is made from flame-retardant plastic with a UL94V-0 rating, providing excellent resistance to combustion and ensuring safe operation in various temperature ranges.

Q: How does its instantaneous mechanical response time benefit digital signal output?

A: Instantaneous switching allows for immediate changes in output signals, which is helpful in applications where rapid, unambiguous setting adjustments are needed without software delays.
